S Series (Ø150-180)
Copied to clipboard
S150U-FT
- Product Feature
Summer, feste Lautstärke (Max. 90dB at 1m) : optional erhältlich
- Voltage
DC:12V,24V│AC:110V,220V
- Dimension
Lens Diameter : │Ø150(Approx.) │Height : 196
- Materials
Linse-PC │Gehäuse-ABS
- Protection rating
IP44
- Certificate
※ Please refer to technical information page for detailed specification including measurement.
(PDF Viewer, PDF Download, Auto-CAD)
Product Feature
Product Feature- Special power transmission system which allows low noise and less wear
- Suitable for Long distance signal transmission by adopting high capacity bulb and large sized reflector
- Mounting bracket allows convenient installation in case of XXX-FT type
- Built-in buzzer available (Volume : Max. 90dB at 1m)
- Revolving speed : 120-140RPM
- Materials : Lens - PC, Housing - ABS, Reflector - PC, Mounting bracket - STS316L
- Ambient operating temperature : -20°C to +50°C
- Protection rating : IP44
Product Specifications
| Model number | Voltage | Current | Bulb | Certificates | Weight | Color | ||
|---|---|---|---|---|---|---|---|---|
| Spec | Standard | Parts no | ||||||
| S150U-FT | DC12V | 1.5A | 12V15W | G23 15S | 17 | | 0.65kg |  R-Red A-Amber G-Green B-Blue |
| DC24V | 850mA | 24V15W | G23 15S | 18 | 0.65kg | |||
| AC110V | 200mA | 12V15W | G23 15S | 17 | 1.04kg | |||
| AC220V | 100mA | 12V15W | G23 15S | 17 | 1.04kg | |||
ㆍSuitable for Long distance signal transmission by adopting high capacity bulb and large sized reflector
※ CE compliant: DC12V, DC24V
