S Series for vehicle
Copied to clipboard
SKMP/ SKMPH
- Voltage
DC:12V,24V
- Dimension
Height : 142 │Length : 185
- Materials
العدسات-PC │المبيت-PC
- Protection rating
IP54
※ Please refer to technical information page for detailed specification including measurement.
(PDF Viewer, PDF Download, Auto-CAD)
Product Feature
Product Feature- Adopts a special power transmission system that reduces noise and wear
- Metal body structure inside the cover gives the product a stylish look
- Exceptional attachment to vehicles which operate in shock and vibration environments The rubber magnet securely attaches along the curved surfaces of the vehicle
- Detachable rubber magnet equipped to prevent potential scratches in vehicle’s surface
- Contains a spare bulb inside the product
- Easy power connection with cigarette lighter plug equipped
- DC(12V, 24V) only
- Materials : Lens-PC, Housing-PC, Reflector-PC/STS
- Revolving speed : 120-140RPM
- Ambient operating temperature : -20°C to +50°C
- Protection rating : IP54
Product Specifications
| Model number | Voltage | Current | Bulb | Certificates | Weight | Color | ||
|---|---|---|---|---|---|---|---|---|
| Spec | Standard | Parts no | ||||||
| SKMP | DC12V | 1.55A | 12V15W | G23 15S | 17 | - | 0.78kg |  R-Red A-Amber G-Green B-Blue |
| DC24V | 765mA | 24V15W | G23 15S | 18 | 0.78kg | |||
| SKMPH | DC12V | 3.5A | 12V35W | 15S halogen | 39 | 0.78kg | ||
| DC24V | 1.85A | 24V35W | 15S halogen | 40 | 0.78kg | |||
